PVC pipe extrusion line is mainly used for producting plastic pipe for agriculture water supply & sewage, for building industries water supply & sewage, for cable and wire laying.
The line consist of twin screw extruder, vacuum tank, cooling tank, haul-off unit, cutter and storage table.
Single extruder and haul-off unit adopt international brand AC inverter speed control, Vacuum pump and haul-off motor use premium bgrand.
The extrusion line can produce pressure water pipes, drainage pipes, industrial pipes and cables duct. The screw structure for the corresponding designed to meet the processing of high filling material(Caco3) pipe requiement, according to the use of pipe, change molds and the corresponding auxiliary equipment, can be processed produce UPVC pipe,CPVC pipe, PVC-M pipe, PVC-O pipe, foam core layer pipe, foam inside the spiral hollow wall spiral pipe.
Haul-off can be equipped with 2/4/6/8/10/12 belt according to the pipe sizes. Cutter can be swarfless, saw blade, or planetary cutting type.
The line featured by stable performance and high efficiency. This line can also produce PE PP inner sprial pipe, hollow pipe, and foaming pipe bychaning the configruation.
The line is fully Automatic control, easy operation, stable performance, reaching international leading level.
Optimized spiral die ensure the melt distribution uniform to make the pipe wall uniform and guarantee the pipe pressure. Equipped copper Vacuum calibration sleeve with water lubrication ring, twin-chamber vacuum tank with spraying cooling and semicircular Nylon support, to ensure fast calibration, increase the production capacity and lower the operation. These designs are especially good for big diameter pipe production and high speed production.
All of vacuum tank and water cooling tank is made from stainless steel, dual water supply pipe line with filtration system, water level and temperature control system and optimized positioning of the bayonet-type spray nozzles.
The twin or multi caterpillar haul-off unit is equipped with high quality rubber block or rubber belt(for high speed production) accuracy driving and control system ensure the speed stable and running reliable.
Accurate non-scrap cutting machine (less than 160mm) and planetary cutting machine ensure the cutting section smooth and uniform.
| Extruder | SJZ-51/105 | SJZ-55/110 | SJZ-65/132 | ||
| Pipe diameter | GF-63 | 16-63 | 16-63 | 50-160 | 50-250 |
| Mould | single pipe | double pipes | double pipes | single pipe | single pipe |
| Downstream equipment | GF-63 | GF-63*2 | GF-63*2 | GF-160 | GF-250 |
| Total power | 60 | 70 | 91 | 85 | 86.5 |
For any inquiry, please contact us directly.
Â
Mobile: 0086-13917356326
 Product Information
PVC pipe extrusion line is mainly used for producting plastic pipe for agriculture water supply & sewage, for building industries water supply & sewage, for cable and wire laying.
The line consist of twin screw extruder, vacuum tank, cooling tank, haul-off unit, cutter and storage table.
Single extruder and haul-off unit adopt international brand AC inverter speed control, Vacuum pump and haul-off motor use premium bgrand.
The extrusion line can produce pressure water pipes, drainage pipes, industrial pipes and cables duct. The screw structure for the corresponding designed to meet the processing of high filling material(Caco3) pipe requiement, according to the use of pipe, change molds and the corresponding auxiliary equipment, can be processed produce UPVC pipe,CPVC pipe, PVC-M pipe, PVC-O pipe, foam core layer pipe, foam inside the spiral hollow wall spiral pipe.
Haul-off can be equipped with 2/4/6/8/10/12 belt according to the pipe sizes. Cutter can be swarfless, saw blade, or planetary cutting type.
The line featured by stable performance and high efficiency. This line can also produce PE PP inner sprial pipe, hollow pipe, and foaming pipe bychaning the configruation.
The line is fully Automatic control, easy operation, stable performance, reaching international leading level.
Optimized spiral die ensure the melt distribution uniform to make the pipe wall uniform and guarantee the pipe pressure. Equipped copper Vacuum calibration sleeve with water lubrication ring, twin-chamber vacuum tank with spraying cooling and semicircular Nylon support, to ensure fast calibration, increase the production capacity and lower the operation. These designs are especially good for big diameter pipe production and high speed production.
All of vacuum tank and water cooling tank is made from stainless steel, dual water supply pipe line with filtration system, water level and temperature control system and optimized positioning of the bayonet-type spray nozzles.
The twin or multi caterpillar haul-off unit is equipped with high quality rubber block or rubber belt(for high speed production) accuracy driving and control system ensure the speed stable and running reliable.
Accurate non-scrap cutting machine (less than 160mm) and planetary cutting machine ensure the cutting section smooth and uniform.
| Extruder | SJZ-51/105 | SJZ-55/110 | SJZ-65/132 | ||
| Pipe diameter | GF-63 | 16-63 | 16-63 | 50-160 | 50-250 |
| Mould | single pipe | double pipes | double pipes | single pipe | single pipe |
| Downstream equipment | GF-63 | GF-63*2 | GF-63*2 | GF-160 | GF-250 |
| Total power | 60 | 70 | 91 | 85 | 86.5 |
For any inquiry, please contact us directly.
Â
Mobile: 0086-13917356326
Â
V Groove Plastic Roller: Hebei Naimei Bearing Co., Ltd. produces kinds of V Groove Plastic Rollers,window roller. which can be applied into sliding doors and sliding windows, aluminium windows and doors, PVC profiles, etc. V Groove Plastic Sliding Rollers/ Bearings in our company is good in quality and cheap in price. They are customized in accordance with customers' designs and drawings. Welcome your inquiry.
Hebei Naimei Bearing Co., Ltd. produces types of plastic bearing rollers:
1). Material: Carbon Steel/ Chrome Steel Bearing + Plastic( POM/ NYLON) Injection;
2). Application: for Aluminium Door and Windows; Aluminium Hardware Accessories and other sliding applications;
3). Plastic Color: Various, as per Request;
-- For any detailed inquiry of Non-Standard Bearing rollers, pls contact us freely. We will make a response within 12 hours.
Sliding Plastic Roller - Factory Direct Hot Sale
Bearing rings: Dimension tolerance, geometric tolerances, and surface quality of bearing` s working surface will influent the operating noise. Naimei Bearing adopts precision CNC machining to dimension precision, geometric tolerances, design drawing, mold making, grinding, cleaning, assembly, testing, every link of strict checks, so as to ensure all our products are tested by our strict criteria.
Balls: The balls evenly with by the cage, often make rolling movement between 2 rings. The shape, size and number will directly influent bearing`s load tolerance and operating capability. We use high precision, small vibration steel ball. It`s surface must be strengthened, no bumps scratches, lacerations, pitting and notch.
Cage: Enclose and move with all or part of the balls. It also be used to insulate the balls, guide the balls` movement and to improve lubrication performance inside the bearing., etc. Naimei Bearing`s cage is commonly made of cold rolling carbon steel. But in the corrosiveness environment, nonparallel or high-speed situation, stainless steel, engineering plastics cagecan be decided on request.
Seal: Naimei Bearing adopts different kind of seal material to meet the requirement of their operating in high temperature and being compatible with grease. Acrylonitrile-butadiene rubber is our standard material. but in high temperature environment ,often adopt fluorocarbons, silicone , PTFE shield.
