Our factory is specialized in different kinds of roll forming machine ,also we can design the machine according to you products details :
Roofing and wall panel roll forming machine ,Glazed tile roll forming machine ,Roof ridge cap roll forming machineÂ
Shutter door roll forming machine ,Pu foam shutter door production line,Door frame roll forming machineÂ
Ceiling keel roll forming machine,Tee grid roll forming machine ,C&Z purlin roll forming machine
Floor decking roll forming machine,Pipe roll forming machine and bending machineÂ
Gutter roll forming machine,Guardrail roll forming machine,Stone coated steel tile production lineÂ
Sandwich panel production line ,Slitting line,Curving machine,Decoiler,Cutting and bending machine
__________________________________________________________________________________________________________
       Â
  C channel sheet metal rolling machine for making roofing ceiling and others
Composition of roof roll forming machine
A. Uncoiler.......................................................................1 unit
B.Main roll forming machine  ·································· 1 unit
C. Control panel·····················································1 unit
D. Hydraulic pump..............................................................1 unit
E.Accepting table................................................................1 unit
Details of each roll forming machine composition:
(1) 4 feet manual uncoiler
(2)Capacity of the uncoiler  : 3 tons
(3) Range of segment expansion  : 460 ~ 515 mm
Â
Main roll forming machine
1. Forming stations  : 14stations
2. Material of roller  : Cr12 steel heat treatment HRC50 and surface is being hard chrome;
3. Shaft : Dia 80mm, high frequency surface treatment and grinding process;the material is 45#steel.
4. Horsepower  : 7.5KWÂ
5. Transmission  : Chains and gears
6. Forming speed  : 45 M/MINUTE
7. Forming thickness : 0.5Â -1.2mm
8. Cutting:No stop cutting machine
  (4) Material of blade: Cr12; heat treatment HRC59~61
  (5) Length measuring: Automatic length measuring
  (6) Tolerance of length: +/- 1.5mm
9. Approximate Size: Length: 5Â M * Width : 1Â M * Height : 1.3M
Control panel
(1) Voltage, Frequency, Phase:Â Customizable
(2) PLC is used to control length & quantity. Machine will automatically
   cut to length and stop when required quantity is achieved
(3) 99 kinds of dimensions can be set in one order at the same time,
   continuously production and nine orders can be keyed-in at a time.
Hydraulic pump
Hydraulic system for cuttingÂ
The motor is used to drive the hydraulic pump ,which enables the hydraulic   oil to drive the hydraulic motor and then drives the main machine.
Accepting table( one manual for free)
1.material: welded steel rube and the rollers with rubberÂ
2.also suggest you the automatic stacker for the highe speed roll forming machineÂ
__________________________________________________________________________________________________________
Machine Pictures
__________________________________________________________________________________________________________
Pre-Sales Service
* Inquiry and consulting support
* Sample testing support.
* View our Factory.
Â
After-Sales Service
* Training how to instal the machine, training how to use the machine.Â
* Engineers available to service machinery overseas.
_______________________________________________________________________________________________________
Packaging | |
Packing method: nude, with waterproof cloth and stow-wood. The computer controlled cabinet is packed with waterproof cloth and box. The seller should guarantee equipment will be moisture-proof, anti corrosive, and will not be damaged during transportation.  | |
__________________________________________________________________________________________
1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.
2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep your business running.
3. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou Xi(1 hour), then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5 hours), then we can pick up you.
4. How to get a quotation?
a. Give me the profile drawing and thickness, this is the important. If no,I will suggest you some.
b. Other specific requirements are welcome, such as the speed, power and voltage you want.
5. What can you do if the machine broken?
Our machine's warranty period is 12months! If the broken parts can't repair, we can send the new parts replace the broken parts free. If after warranty period,we can through negotiation for to solve the problems, and we supply the technical support for the whole life of the equipment.
6. Can you be responsible for transport?
Yes, please tell me the destination port or address. We have rich experience in transport.
7. You are trade company or factory?
We are factory. Welcome to our workshop for visiting.
8. How long the machine could be made?
Normally speaking, common roof profile roll forming machine could be made within 45 working days.
If you need machines in a hurry, we can make it for you less than a month.
If need more machine pictures or videos,welcome to contact me.
